Sacs
rebel 47

Length O. A.: 14,06 mt
EC certifying length: 13,07 mt
Max beam: 4,41 mt
Keel draft (at propeller): 0,70 mt (1,00 mt)
Hull type (dead rise): Deep V (19,2°)
Tubes diameter: D Shape
Weight with standard engines: 12,0 t.
Fuel tank capacity“: 1.500 lt
Water tank capacity: 225 lt
Waste Tank capacity: 52 lt
Maximum installable power: 648 kW
Homologation category: CE – B
Persons capacity: 18
Project: SACS
Design: Christian Grande Design Works

STANDARD EQUIPMENT
Deck
Anti collision foam filled D-shape profiles
4 disappearing mooring cleats
Anchor windlass with double control (bow and helmstation)
Ultra Marine polished stainless still anchor 16 kg with 50 mt stainless steel chain diam 8
Disappearing bow shower with cold/hot water mixer
Double chaise longue with headrest and rails
Bow sunbed with handrails
Full walkaround with stainless steel handrails
Stern platform with massive teak decking
Helm Station
Compass
Anti rifraction black plexiglass dashboard
Isotta steering wheel
Engine monitor Volvo EVC 4“‘
Digital control panel with vandal proof switches
Lopolight navigation lights
Horn
USB charging point
3 bolster armchair
Dashboard cover
Cockpit
Cockpit bar with sink, corian worktop, drawers and cupboards
Inox drawer fridge/feezer
Hard Top spotlights
Dining table in teak
Double sofa counterplaced with storage underneath
Stern sunbed with headrest
Stainless steel gates in the cockpit
Garage with hydraulic opening
Disappearing cockpit shower with cold/hot water mixer
Stainless steel swim ladder with teak steps
Fuel System
Twin 750 lt. steel compensated fuel tanks with double filling cap (port and starboard)
Pyroff anti fire protection (manual and automatic)

Master cabin
Dinette with 2 place couch and bookshelf
Super queen size bed
Bedsides shelves with LED reading lights and USB charging
Wardrobe with hangers and shelves
Side windows with disappearing curtains
Central porrthole
Headroom
Electric Toilet with waste level indicator
Bathroom cabinet with laquered top, sink with mixer tap and mirror
Shower room with seating, adjustble water mixer and rainshower
Guest cabin
Queen size bed
Wardrobes and shelves
LED reading lights and USB charging
Double wardrobes on the side of the bed
Electric system
Main control switch panel in dinette
Electronic battery switch
Engine room hydraulic opening
4 Engine batteris 80 Ah
6 batteries of 105 Ah for services and appliances
Electronic and automatic Battery chargers 2 x 50 Ah
220 Volt system with Shuko plugs in all rooms
USB chargin ports in every room and at the helmstation
Shore power system with cable 32 Ah
Water System
Stainless steel fresh water tank 225 lt.
Double cicruit water heater 25 lt
Twin body water pressure pump with conpensation tank
Waste tank 52 lt with macerrator pump and suction plug on deck
Safety
3 electric automatic bilge pump with alarm
3 high capacity manual bilge pumps for safety backup

STANDARD COLORS:
White gelcoat hull and deck RAL 9016, console, bar top, bow step and eventual Sport Top painted in Silver F426
Ice white tube with grey profile, Neptune Grey SACS logo, silvertex Sandstone upholstery, grey bimini
Breezed oak interior veneer with white Top and revestments

COLOR OPTIONS
STYLE PACK
Hull and deck in Grey gelcoat RAL 7035 in alternative to the white
Consolle and Hard Top custom painting antracite H216
Custom tube color black carbon with black profile and neptune grey logo
Deck upholstery in custom fabric Serge Ferrari Light Grey
Custom paint color deck in silver F426 and hull topsides in antracite H216, bottom excluded
Massive teak decking and platform with grey caulking
Premium interior finishing with selected veneer, leather panels and matching laquered details (To be defined)

CRUISE PACK
Bow Thruster
Bimini top with carbon fiber poles
1200 Watt Inverter with additional batteries
Fusion stereo system with bluetooth function

ELECTRONIC PACK
2 x GPS Raymarine Axiom + 12“ Glass Bridge with depth finder module
Engine data interface on GPS
Raymarine „Domotic“ interface
VHF

VISIBILITY PACK
Cockpit, cabin and Hard Top courtesy LED lights with dimmer
Stern underwater lights
Windshield wiper
Night and Day camera in the anchor compartment
Wireless remote control for anchor windlass with chain meter counter

POWER PACK
Diesel Power Generator Onan 4 KW
Air conditioning Hot / Cold reversible (12.000 btu)
Induction electric cooktop

OTHER FACTORY OPTIONS
New carbon fiber hard top with Y Central support and tempered glass windshield, painted in antracite H216
Bow removable bimini with carbon fiber poles
Volvo Penta Joystick system for sterndrives
Automatic pilotFull Glass Cockpit upgrade with twin 16“ gps screen and no analogic engine gauges
Raymarine AIS system Rx / Tx
JL Audio sound system upgrade (8 speakers/ 1 subwoofer/1 ampli)
Cockpit electric tableDouble inox drawer fridge (50 lt + 50 lt) in cockpit
50 lt drawer fridge in master cabin
2000 Watt inverter upgrade with dedicated batteries
Stern surveillance camera
Control camera in anchor compartment
Transformer hydraulic platform
Cover set for bow and stern sundeck, kitchen and driving seats

DELIVERY OPTIONS
On board equipment (6 Fenders with Sacs covers – 4 Mooring lines – Toolkit Beta 55 pcs )
Antifouling
Freight and pre delivery at Marina di Varazze
CE hull and engine power certification
