Bluegame
BGX60 #02

HULL DECK CONSTRUCTION
Molded fiberglass construction made with iso- neopentilic gelcoat, skin coat of vinylester resin
Bottom hull in monolithic lamination made with biaxial, glass and ISO DCPD polyester resin
Sandwich core construction on side hull and deck plans Infused sandwich structural bulkheads
Antifouling on Hull

UPPER DECK
Deck made in sandwich and infusion technology with vinylester resin
Twin fiberglass doors covering anchor system Anchor 30 Kg S/S
Bow roller custom design S/S Galvanized chain 12 mm 100 m Anchor safety cable
Electric anchor winch 2000 w Electric mooring winch 1000 w Two S/S fairlead
Two S/S cleats 360 mm
Two retractable cleats amidship Fresh water outlet connection Teak deck
Access to crew cabin at the bow Sun pad area with back rest
Double side entrance from the dock
Two teak tables in bow area
Bow sofa on both side Storage
Navigation and anchor lights led systems Courtesy light on walkaround
Dimmable ceiling lights Double diesel inlet Fresh water inlet
Black water tank drain pump Grey water tank drain pump Horn
Radar radome GPS antennas
VHF antennas
Four speakers (two in cockpit two in bow) connected to the deck house area
Upper deck sliding glass door
Port side manual pantograph door
L shape sofa on stern with teak table Glass skylight on portside
Storage
Sun roof ladder with manual hatch Sun roof handrails
Antiskid floor on sundeck Digital TV Antenna

BEACH AREA
Two speakers and subwoofer connected to the salon area
Teak stairs to upper deck
Sliding glass door to main salon
Side 180° crane with 500 kg lifting capacity Retractable up/down gangway
Electrical engine room large hatch for maintenance Manual engine room access
Two stern mooring winches 1000 W Two stainless steel cleats 360 mm Hot/cold shower
Teak deck
Side storage compartments Floor storage comparments Courtesy lights
Dimmable ceiling lights Two glass skylights

DECKHOUSE
Sliding glass door with curtain Wooden floor
Blinds
Dimmable led lights
L shape sofa with table and 3 chairs/stools Pilot and copilot bench
Storages below the pilot seat
Console with: HI-FI
Compass
Two 12” chart plotter glass cockpit indicating engines parameters (rpm, oil pressure, water temperature, engine sound warning alarm, fuel and water level) and controls (intruder systems, windshield wiper, GPS, radar, fish-finder)
Volvo Penta automatic pilot
VHF station with passive AIS receiver IPS Joystick
Volvo Penta electronic engine throttle
Digital switching and digital automation for main services DC and AC integrated in main panel
Back-lighted switch panel for deck services Bluegame personalised steering wheel
Fire control for manual extinguisher Red navigation light control
Port side manual pantograph door Power and USB sockets
Stairs from main saloon with handrail Stairs to guest’s area with handrail Side tempered glass
Air conditioning fan coils Fire extinguisher 1 kg

GALLEY
Painted overhead cabinet
Lower painted cabinet with storage Sink
Synthetic worktop
Four zone induction cooktop with pan holders Oven
Refrigerator
Freezer
Kitchen hood
Power sockets
Trash compartment

SALON
Sliding door to beach area with curtain Steps from beach area to salon
Power and USB sockets Dimmable lights
L shape fabric sofa
One Ottoman
Two coffee tables
Wooden floor Carpet
Blinds
Side tempered glass 50” TV
Stairs to deckhouse Owner cabin entrance HI-FI
Four speakers
Air conditioning fan coils Floor hatch to storage area
Storage cabinet with fridge
Fire extinguishers 1 Kg

OWNER CABIN
Double bed with memory foam mattress Storage cabinet
Nightstands Carpet floor Reading lights Ceiling lights Courtesy lights
Power and USB sockets
Side tempered glasses with integrated porthole
Blinds
Pillows
Bed sheet cover Bed sheets
Safe
32” TV
HI-FI
Two speakers
Vanity desk with one stool
Walk-in-wardrobe
Starboard side lounge area with sofa, coffee table and porthole
Air conditioning fan coil Fire extinguisher 1 Kg

OWNER BATHROOM
Fresh water electric marine WC Bidet
Wooden floor
Bathroom towels
Ceiling Lights
Blind
Power sockets
Bathroom accessories
Cabinet with mirror
Porthole
Synthetic surface with integrated double sink Air conditioning outlet
Shower with handset, ceiling shower head and tempered glass door

VIP CABIN
Double bed with memory foam mattress Storage cabinet
Nightstands Wardrobe Carpet floor Reading lights Ceiling lights Courtesy lights
Power and USB sockets Porthole
Blinds Pillows Bed sheets
Bed sheet cover
32” TV
HI-FI
Two speakers
Air conditioning fan coil Fire extinguisher 1 Kg

VIP BATHROOM
Fresh water electric marine WC Wooden floor
Ceiling lights Blind
Bathroom towels
220 V sockets Bathroom accessories Cabinet with mirror Porthole
Synthetic surface with integrated sink Air conditioning outlet
Shower with handset and tempered glass door

GUEST CABIN (OPTIONAL)*
2 crossed single bed with memory foam mattresses
Wardrobe
Carpet floor Reading lights Ceiling lights Courtesy lights
Power and USB sockets Porthole
Blinds Pillows Bed sheets
Bed sheet covers
HI-FI
Two speakers
Air conditioning fan coil Fire extinguisher 1 kg
(* Owner cabin standard features will result modified by this optional)

GUEST BATHROOM (OPTIONAL)*
Fresh water electric marine WC Wooden floor
Ceiling lights Blind
Bathroom towels
220 V sockets Bathroom accessories Cabinet with mirror Porthole
Synthetic surface with integrated double sink Air conditioning outlet
Shower with handset and tempered glass door
(* Owner cabin standard features will result modified by this optional)
LOBBY
Storage compartment
Teak stairs from deckhouse to lower deck Courtesy lights
Floor hatch to storage area
CREW CABIN
One bunk bed (+ one opt)
Storage cabinet Reading lights Ceiling lights Porthole Synthetic floor
Blinds
Pillows Bed sheets
Bed sheet covers
Power and USB sockets Air conditioning fan coil Separate bathroom with:
Fresh water electric Marine WC Synthetic floor
Ceiling lights Power socket
Bathroom accessories Storage cabinet Porthole
Shower
Crew set uniform

ENGINE ROOM
2 x Volvo IPS 1050 D13 / 2 x 588 kW / 800 HP @2300 RPM
3000 l fuel structural tank in composite with fuel level sender connected with EVC Volvo system 7
Automatic valves for fuel shout-off Double fuel filter separator
Fire extinguisher system with manual and automatic control
Engine room led lights AC chiller unit 60000 btu Engine room insulation
Two electrical ventilators with cycle reversion and thermostat switch
Air inlet with water separator filters Watertight power sockets
Water Filter
Opening engine room cover Optical smoke detector Overpressure detector integrated
with Garmin automation
S/S engine room access ladder Intruder trim system

HYDRAULIC SYSTEM
700 l polyethylene freshwater tank with level indication on main panel
80 l boiler 220 V
Black water tank 330 l with level indication on main panel
Gray water tank 330 l with level indication on main panel Shore black water discharge system 24 V
Shore grey water and bilge discharge system 24 V
Double fresh water pump 24 / 230 V
Black water hoses in special anti smell rubber High pressure fresh water inlet from shore
Six bilge pumps; two in engine room, two in stern area and two in center hull, with automatic
and manual control

ELECTRICAL SYSTEMS
Generator 18.0 kW
Four batteries 12 V / 130 Ah AGM for engines Electromechanical switching for batteries
with remote control
8 Service Gel batteries pack 24 V / 660 Ah One battery 12 V / 165 Ah for generator
Battery charger 24 V / 80 Ah for services
Battery charger 24 V / 30 Ah for engines Battery charger for generator
230 V shore power 62 A with connection cable 15 m Galvanic Isolator 62 Ah
Inverter 2000 W
AC Electrical Panel (230 V) CE certified on electrical room with electromechanical switching for all outlet with remote control on main panel
DC Electrical Panel (24 V) CE certified on electrical room with electromechanical switching for all outlet with remote control on main panel

FUNCTIONALITY
Volvo Penta IPS1200 (diff. From STD IPS1050)
Glendenning Cabelmaster CRMA 63
Bow Thruster 170 kgf
Search Light with remote control
DPS for Volvo Penta IPS
kit toilet fan extractor

DECORATION
Kitchen BOFFI
2 cabins / 2 toilets Lay-out
Electronic
WI-Fi system + 2 REPEATERS
Volvo glass cockpit 16″ different from 12″ STD (n° 2)
Flir night vision camera M232 1
CCTV System 3 fixed cameras (2 Engines room 1 in cockpit)
AIS system for Garmin 700 Rx/Tx

COMFORT
a/c tropical
Opening roof top kit in deckhouse
Lithium batteries
Teppan yaki in wetbar
Wetbar in beach area equipped with basin, fridge, storage and rubbish can
Icemaker in wetbar
Up-Down TV movement in LD salon
Winecooler in LD salon
Bow sunlounge bimini
Stern sunlounge bimini
Bow area tables electrically up/down with cushions for sunbed extension
Watermaker unit 130 Lt /h 1
Additional safe
Additional fridge (bow)
winecooler (under pilot seat)
Dishwasher (6 place set)
Washmachine+drymachine BOSCH
WC and integrated bidet in owner bathroom (instead of wc + bidet)

SERVICE
Propspeed on IPS
Set of fender covers and rope covers

CUSTOM
Mosquito screens for hull windows
Carbon side ladder
Entrance with door from owner’s cabin to guest cabin
Kit tender installation on beach area
Leather Veneziane blinds in upper deck (white) with dometic system
Leather Veneziane blinds in lower deck (white) with dometic system
N.2 empty domes painted in deck house color
External manouvring station
N.2 additional cameras (outside lateral view and inside anchor locker)
External upholstery in fabric RODA PLTO D01 COL. SAND
N.2 Roda Orson 001 director chairs, structure in teak and BATY fabric col. SAND
N.2 Storage cover for director chairs RODA ORSON 001
N.12 decorative cushions in fabric MF ZAGORA col. 102
Garmin OnDeck
SALOON: L-Shape sofa Living Divani ROD – Fabric Mirage col.02 + structure in leather Florence 00/8
SALOON: 1x Coffee table Poltrona Frau „Bob“ D60 H43 in leather SC68 SAHARA
SALOON: carpet Living Divani Sin Titulo 3 240×170 cm
SALOON: 1x lamp Atollo Oluce black 1 OWNER’S AND VIP’S CABINS: Moquette Supertuft Milford
OWNER’S AND VIP’S CABINS: 1x Pouf Nina Caresse col. 801
OWNER’S AND VIP’S CABINS: 1x coffee table Poltrona Frau „Bob“ D60 H43 in leather SC68 SAHARA
Interior extra cushions: OWNER’S AND VIP’S CABINS: decorative cushions:, 4x fabric Rubelli reloaded
col. Ivory; 7x fabric Z&R Nelson col. 286, DECORATIVE CUSHIONS UPPER DECK SOFA – 3x FABRIC Z&R
FABRIC RUBELLI RELOADED COL. IVORY + 3x FABRIC Z&R NELSON COL. 286, DECORATIVE CUSHIONS 1 LOWER DECK SOFA -3x FABRIC Z&R FABRIC RUBELLI RELOADED COL. IVORY + 3x FABRIC Z&R NELSON
COL. 286
UPPER DECK: sofa’s fabric Z&R Spirit col. 881 1
UPPER DECK:2x stools B&B Italia „Frank“ Edit col. 450 1
OWNER &VIP CABIN BEDSPREADS – FABRIC RUBELLI BRODERIE COL. 06 1
OWNER CABIN SOFA – FABRIC Z&R „GIPSY“ COL. 880 1
Stainless steel boat name „Caruso 1
Exterior cushions n.6 Talenti Icon_Pascal C9 Brick Red + n.6 Jim Thompson_Padang JT013717006_Terracotta
Safety kit: Syntesy raft 9650-1 8TO / V />24GB (Transport Included), buoy light for lifejacket, rocket kit signaling over 12 miles, lifejacket, rocket kit signaling over 12 miles, lifejacket with accessories, life 1 belts
